SUS316 Stainless Steel Injection Molding Medical Surgical Knife Handle ISO9001

Passivated SUS316 Medical Stainless Steel Injection Molding Surgical Knife Handle

• Metal injection molding combines the precision of plastic molding with the strength of metal, creating complex parts efficiently, perfect for producing small, complex components efficiently.
• MIM(Metal Injection Molding) is an advanced manufacturing technique that combines plastic injection molding and metal properties. It is best suited to small detail parts, usually in the weight range of 1 to 100 grams of metal. The beauty of MIM manufacturing lies in its ability to easily generate intricate shapes with very tight measurements, which is why the MIM process is used in a wide range of applications, from medical devices to aerospace accessories.

Product Analysis

Material and process:
Aerosolized 440C stainless steel powder (C: 1.0%, Cr: 17%, Mo: 0.6%)
Hot isostatic pressing (HIP 1180 ° C/100MPa) achieves 99.98% density

Surface performance:
Vacuum quenching+cryogenic treatment, surface hardness HV600 ± 20 (ISO 6507)
CrN coating (3 μ m), friction coefficient ≤ 0.15 (ASTM G99)

Structural design:
Spiral groove silicon nitride ceramic particle reinforcement (increased wear resistance by 3 times)
Internal honeycomb cooling channel (mold temperature control accuracy ± 1.5 ° C)

Comparison of similar products

Typical application
In the automotive field:
Injection molding of long fiberglass PP bumper (barrel temperature 280-320 ° C)
Compared to traditional screw heads, the wear per unit output has been reduced by 62%, and the mold replacement cycle has been extended to 3 weeks

Electronic packaging:
LCP liquid crystal polymer 5G antenna injection molding (shear heat sensitive material)
The internal cooling channel causes the temperature fluctuation of the melt to be less than ± 2 ° C

Medical consumables:
Formation of PEEK skull repair parts (resistant to gamma ray sterilization cycle)
Surface CrN coating has passed ISO 10993 biocompatibility

Polestar Metal: Your Trusted Partner in Precision CNC Manufacturing

Choosing our CNC machining services ensures not only precision and quality but a partnership built on trust and reliability. At Polestar Metal, we are committed to delivering excellence in every aluminum component we produce. From prototyping to full-scale production, we are equipped to meet your specific needs and bring your designs to life.

CNC Machining Tolerance:
