Micro Brass Cnc Turned Components Gold Plated Customed For 5G Base Station RF Connectors
-
Highlight
Micro Brass Cnc Turned Components
,Micro cnc machining turning parts
,Gold Plated Brass Cnc Turned Components
-
ServiceCustomized OEM CNC Machining
-
DimensionCustomized
-
OEM/ODMYes
-
Accuracy+/-0.0025mm
-
CustomizedFree Design And Sample
-
KeywordMedical Appliances, Turning, High Precision
-
EquipmentCNC Machining Turning Centres
-
ShippingExpress, Air, Sea
-
DeviceCNC Machining Center
-
FinishSmooth, Matte, Glossy
-
Place of OriginChina
-
Brand NamePolestar
-
CertificationISO9001, TS16949
-
Model NumberAs Drawing
-
Minimum Order Quantity200pcs
-
PriceAccording to the detailed drawing
-
Packaging DetailsCarton + Pallet, Customized package is available
-
Delivery Time3-20days
-
Payment TermsL/C,D/A,D/P,T/T
-
Supply Ability10000pcs per day
Micro Brass Cnc Turned Components Gold Plated Customed For 5G Base Station RF Connectors
Micro CNC Turned Parts Gold Plated Customed For 5G Base Station RF Connectors
Technical Specifications and Process Advantages
The micro CNC turning gold-plated parts designed specifically for 5G base station RF connectors use micrometer level precision machining technology (tolerance ± 0.005mm) to ensure the geometric accuracy and stability of high-frequency signal transmission. Through customized turning technology, the inner diameter of the component can be accurately adapted to RF interface standards such as 2.92mm/4.3-10, with a surface gold plating layer thickness of 0.1-0.25 μ m, contact resistance<5m Ω, and insertion loss ≤ 0.15dB@40GHz Significantly better than traditional nickel plating process (insertion loss ≥ 0.3dB).
Specifications
|
Raw Material |
Aluminum like 6061 7075 5052 2024 6082 6063 5083 2011 7050 7075-T6,Stainless steel like 301 302 303 304 305 309 310 316 317 321 347,Brass H59 H62 H63 H65 H68 H70 H75,Titanium alloy like TA1/2/3/4/5 TC4/6/11 and any other metal or plastic you need |
|
Process techology |
CNC machining,turning,milling,cutting,welding, etc |
|
Surface treatment |
Electroplating, sandblasting, anodizing, polishing, passivation, etc. |
|
Colour |
Customed |
|
MOQ |
50PCS |
|
Accuracy |
+/- 0.0025mm |
|
Equipment |
CNC machining centers, CNC lathes, grinders, engraving machines, etc. |
|
Inspection |
Calipers, Micrometers, CMM |
|
Application |
Surgical instruments, implants, medical equipment parts |
|
Delivery Time |
2-3weeks |
The Advantages of Turning
Firstly, turning machining can achieve extremely high dimensional and shape accuracy, typically reaching IT6-IT7 levels. Secondly, high-efficiency turning has fast processing speed and is suitable for large-scale production. In addition, complex shape processing.Complex shapes such as surfaces, threads, grooves, etc. can be machined using a CNC lathe. Therefore, the turning process can meet the strict requirements of the medical industry for high precision, high cleanliness, complex shapes, and material diversity.
CNC Machining Tolerance
|
Precision Machining |
Metals, PEEK, And |
Other Plastics |
No Drawing |
|
Linear Dimension |
+/- 0.0025 mm |
+/- 0.05 mm
|
ISO 2768 Medium |
|
Hole Diameters |
+/- 0.0025 mm
|
+/- 0.05 mm |
ISO 2768 Medium |
|
Shaft Diameters |
+/- 0.0025 mm
|
+/- 0.05 mm
|
ISO 2768 Medium |
Why Choose Us to Process for You?
Choosing our CNC machining services ensures not only precision and quality but a partnership built on trust and reliability. At Polestar Metal, we are committed to delivering excellence in every aluminum component we produce. From prototyping to full-scale production, we are equipped to meet your specific needs and bring your designs to life.
Our products are sold all over the world, you can rest assured.
